| Brand Name: | TORICH |
| Model Number: | ASTM A500/500M |
| MOQ: | 5 tons |
| Price: | negotiable |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 50000 tons per year |
Applications:
for construction of bridges, and buildings, and for general strcutrual purposes
Size range:
Square tubes O.D. :20-20 to 500-500mm W.T.:1-24mm L:max12000mm
Rectangle tubes O.D. :20-30 to 400-600mm W.T.:1-24mm L:max12000mm
| Tensil requirements | ||||
| Round Structural Tubing | ||||
| GradeA | Grade B | Grade C | Grade D | |
| Tensil strengths,min,psi(Mpa) | 45 (310) | 58(400) | 62(425) | 58(400) |
| Yield strength,min,psi(Mpa) | 33(230) | 42(290) | 46(315) | 36(250) |
| Elongation in 2 in.(50mm) min,% | 25 | 23 | 21 | 23 |
| Shaped Structural Tubing | ||||
| GradeA | Grade B | Grade C | Grade D | |
| Tensil strengths,min,psi(Mpa) | 45 (310) | 58(400) | 62(425) | 58 |
| Yield strength,min,psi(Mpa) | 39(270) | 46(315) | 50(315) | 36(250) |
| Elongation in 2 in.(50mm) min,% | 25 | 23 | 21 | 23 |
