Drill Steel Pipe
Created with Pixso.

API 5CT J55 N80 Oiled Carbon Drill Casing Pipe Cold Rolled

API 5CT J55 N80 Oiled Carbon Drill Casing Pipe Cold Rolled

Brand Name: TORICH
Model Number: API 5CT
MOQ: 50 Ton
Price: $1150-1400/ton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 80 tons
Detail Information
Place of Origin:
China
Certification:
ISO,CE
Product Name:
TORICH API 5CT J55 N80 Oil Casing Carbon Steel Pipe Fluid Tube Drill Pipes
Standard:
API 5CT
Surface Finish:
Oiled
Type:
Carbon
Shape:
Round
Keyword:
Oil Casing Steel Tube
Packaging Details:
EN10305-4 BKS E355 High Pression Cold Drawn Steel Pipe in hexagon packing
Supply Ability:
80 tons
Highlight:

Cold Rolled Drill Casing Pipe

,

API 5CT Drill Steel Pipe

,

Oiled Drill Casing Pipe

Product Description

TORICH API 5CT J55 N80 Oil Casing Carbon Steel Pipe Fluid Tube Drill Pipes



Grade: H40, J55,K55, N80, L80, C90,T95, P110, Q125, V150

Function: Steel pipes used to support oil and gas well walls.

Application: Petroleum casing is a large-diameter pipe that serves to fix oil and natural gas well walls or boreholes. The casing is inserted into the borehole and fixed with cement to help the borehole separate the rock formations and prevent the borehole from collapsing, while ensuring the circulation of drilling mud to facilitate drilling and exploitation.

Length: R-1:4.88~7.62m,R-2:7.62~10.36m,R-3:10.36m to more.





Grade C Si Mn P≤ S≤ Cr≤ Ni≤ Cu≤ Als≤
API 5CT J55 0.34-0.39 0.2-0.35 1.25-1.5 0.020 0.015 0.015 0.2 0.2 0.02




Mechanical Proporties:

Steel Grade
Yield Strength (Mpa)
Tensile Strength (Mpa)
API 5CT J55
379-552
≥517



Dimension Tolerance:

Types of steel tubes Outer Diameter Wall Thickness
Cold-rolled tubes Tube sizes(mm) Tolerances(mm) Tolerances(mm)
≤101.6 ±0.79 -12.5%


Show:

API 5CT J55 N80 Oiled Carbon Drill Casing Pipe Cold Rolled 0API 5CT J55 N80 Oiled Carbon Drill Casing Pipe Cold Rolled 1API 5CT J55 N80 Oiled Carbon Drill Casing Pipe Cold Rolled 2API 5CT J55 N80 Oiled Carbon Drill Casing Pipe Cold Rolled 3



FAQ

Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but you need to pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
If you have another question, pls feel free to contact us



QUALITY CONTROL

1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
